CyberPower 40KVA/40KW Rack UPS
CyberPower 40KVA/40KW Rack UPS. CyberPower 40KVA/40KW Rack UPS
Specifications:
- Phase: Three Phase
- Form Factor: Rackmount, Tower
- UPS Topology: Online Double Conversion
- Energy Saving Technology: Online ECO Mode Efficiency > 98.9%
- Normal Mode Efficiency ( % ): 95.8%
- Battery Mode Efficiency ( % ): 95.5%
- Active PFC Compatibility: Yes
- Parallel Expansion (Max. Units): 4
- Dual Power Inputs: Yes
- Generator Compatibility: Yes
- Nominal Input Voltage ( Vac ): Line to Neutral (L-N):220, 230, 240 Vac, Line to Line (L-L):380, 400, 415 Vac
- Input Voltage Range ( Vac ): Line to Neutral (L-N): 132 ~ 276 Vac, Line to Line (L-L): 228 ~ 478 Vac
- Input Frequency Range ( Hz ): 40 ~ 70
- Rated Input Current ( A ): 64.5
- Input Power Factor: 0.99
- Overload Protection (Bypass): 125% Load for continuous operation, 150% Load for 10 min, 1000% Load for 5 ms
- Input Connector Type: Hardwire Terminal Block
- Capacity (VA): 40000
- Capacity (Watts): 40000
- On Battery Waveform: Pure Sine Wave
- Output Voltage Setting: Configurable
- Output Frequency Setting: Configurable
- Rated Output Voltage ( Vac ): Line to Neutral (L-N):220, 230, 240 Vac, Line to Line (L-L):380, 400, 415 Vac
- Output Voltage Tolerance ( % ): Balance Load: 1 %
- Output Frequency ( Hz � % ): 50 � 0.2, 60 � 0.166
- Power Factor: 1
- ECO Mode Voltage Tolerance: � 5 %
- Overload Protection: Internal Current Limiting, Fuse
- Overload Protection (Line Mode): 102~110% Load for 60 min, 110~125% Load for 10 min, 125~150% Load for 1 min, >150% Load for 200 ms
- Overload Protection (Battery Mode): 102~110% Load for 60 min, 110~125% Load for 10 min, 125~150% Load for 1 min, >150% Load for 200 ms
- Crest Factor: 3 : 1
- Harmonic Distortion (Linear Load): THD?1%
- Harmonic Distortion (Non-linear Load): THD?3%
- Internal Bypass: Automatic Bypass
- Synchronization Window (Nominal) ( Hz ): � 4
- Outlet Type: Hardwire Terminal Block x 1
- Typical Transfer Time ( ms ): 0
- Maximum Charging Current ( A ): 12
- Typical Charging Current ( A ): 3.6
- Compatible Battery Types: VRLA
- Recharge Power Setting: Configurable
- Charger Voltage Tolerance ( % ): ? 1 %
- Start On Battery: Yes
- Smart Battery Management (SBM): Yes
- Compatible Extended Battery Module (EBM): BME480V55ART5U
- External Battery Quantity: 12V x 40pcs
- EMI/RFI Filtration: Yes
- LCD Panel: Yes
- LCD Types: Color LCD, LCD Touch Panel
- LCD Orientation: Rotatable LCD ? Manual
- LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
- LCD Setting & Control: Mode Setting, Input & Output, Battery Setting, Communication, Event & Log, Security Setting, Language
- LED Indicators: Yes
- Shortcut Button: Alarm On/Off
- Serial Port: RS232 x 1 + RS485 x 1 + Dry Contact x1
- Dry Contact (with Relay): Yes
- Emergency Power Off (EPO) Port: Yes
- Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery
- Power Management Software: PowerPanel Business (Recommended)
- SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
- Compatible with Racks (3 Phase): Yes
- Enclosure Construction: Metal
- Color: Black
- Ingress Protection: IP20
- Rackmount Rail: Yes
- Dimensions (mm.): 433 x 219 x 730
- Weight (kg.): 42.8
- Installed Rack Height ( U ): 5
- Operating Temperature (�C): 0 ~ 40
- Operating Relative Humidity (Non-condensing) ( % ): 0 ~ 95
- Operating Elevation (meters): 0-3,000
- Storage Temperature (�C): -40 ~ 70
- Storage Relative Humidity (Non-condensing) ( % ): 0 ~ 95
- Audible Noise at 1.0M from Surface of Unit: 66dBA(100% load), 56dBA(50% load)
Features:
- Three-phase Design
- High Output Power Factor
- Color LCD Panel
- Dual Inputs
- Pure Sine Wave Output
- Battery Cold Start
- SNMP/HTTP Remote Management Capability (Optional)
- Extended Battery Module (EBM)
- Online (Double Conversion) UPS Topology
- Rack Modular Design
- LCD Touch Panel
- Generator Compatible
- UPS Parallel Expansion
- Smart Battery Management (SBM)
- PowerPanel Management Software
